HOMEPAGE >> PRODUCTS >> RLEIL ROCKER SWITCH >> RL2 SERIES

RL1-121/N-C-2-RE/BK-P2
ON-OFF 4P W/Lamp DPST
RL2-121/N-C-2-BK/BK-P2
ON-OFF 4P DPST
RL2-121-P-2-BK/BK-P2
ON-OFF 4P W/PVC-CAP
PVC-CAP



SPECIFICATION:
16(4) A 250VAC T85
16(4) A 250VAC T125 1E4
15A 125V/8A 250VAC

EXPLANATION OF MODEL NUMBER
R L 2 - 1 -
2 1 / N
- C
- 2
- R E / B K
- P 1

|
|
|
|
|

Function
Cap Type
Cap Printing
Cap/Housing Color
Terminal

Function
21/N
ON-OFF 4P
W/Lamp
21
ON-OFF 4P
22
ON-ON 6P
23
ON-OFF-ON 6P
11
ON-OFF 2P
12
ON-ON 3P
Cap Type
A
Flat
C
Soft Line
P
W/PVC Cap
Cap/Housing
Color
BK
Black
WT
White
RE
Red
GR
Green
BL
Blue
OR
Orange
Terminal
Cap Printing
0
None
3
6
1
4
7
2
5
8
