HOMEPAGE >> PRODUCTS >> RLEIL ROCKER SWITCH >> RL3 SERIES

RL3-421/N-G-2-RE/BK-P8
ON-OFF 4P W/Lamp DPST
RL3-421-G-2-BK/BK-P8
ON-OFF 4P DPST
PVC-CAP


SPECIFICATION:
(G) : 6(2) A 250VAC T125
10A 125VAC
(H) :10(4)A 250VAC T125 IE4
16A 125V/10A 250VAC 1/3HP 125-250VAC T105

EXPLANATION OF MODEL NUMBER

R L 3 - 4 -
2 1 / N
- G
- 2
- R E / B K
- P 8

|
|
|
|
|

Function
Current
Cap Printing
Cap/Housing Color
Terminal

Function
21/N
ON-OFF 4P
W/Lamp
21
ON-OFF4P
11/N
ON-OFF 3P
W/Lamp
11
ON-OFF 2P
Current
G
10A125VAC
6A250VAC
H
16A125VAC
10A250VAC
Cap/Housing
Color
BK
Black
WT
White
GE
Grey
RE
Red
GR
Green
OR
Orange
Terminal
Cap Printing
0
None
1
2
3
8
15
29
