HOMEPAGE >> PRODUCTS >> RLEIL ROCKER SWITCH >> RL3 SERIES

RL3-511/N-G-2-RE/BK-P5
ON-OFF 3P W/Lamp
RL3-511-G-2-BK/BK-P5
ON-OFF 2P
RL3-511/N-MIR
ON-OFF 3P W/Round Len
RL3-500-G-0-RE/WT-P4
INDICATOR LAMP

SPECIFICATION:
(G) :6(2) A 250VAC T125 IE4
10A 125VAC
(H) :10(4)A 250VAC;6(4) A 250VAC 5E4
16A 125V/10A 250VAC 1/3HP 125-250VAC T105

EXPLANATION OF MODEL NUMBER

R L 3 - 5 -
1 1 / N
- G
- 2
- R E / B K
- P 5

|
|
|
|
|

Function
Current
Cap Printing
Cap/Housing Color
Terminal

Function
11/N
ON-OFF
W/Lamp
11
ON-OFF 2P
12
ON-OFF 3P
13
ON-OFF-ON 3P
21(ON)
(ON)-OFF 2P
00
Indicator Lamp
Current
G
10A125VAC
6A250VAC
H
16A125VAC
10A250VAC
Cap/Housing
Color
BK
Black
WT
White
GE
Grey
RE
Red
GR
Green
OR
Orange
Terminal
Cap Printing
0
None
1
2
3
4
5
6 7 8
21
22
23
24
25
26
27 33 34
35 36 37
