HOMEPAGE >> PRODUCTS >> RLEIL ROCKER SWITCH >> RL3 SERIES


RL3-311/N-G-2-RE/BK-P4
ON-OFF W/Lamp
RL2-311/N-G-2-GR/BK-P4
ON-OFF W/Lamp

PVC-CAP


SPECIFICATION:
(G) :
6(2) A 250VAC T125 1E4
10A 125VAC
(H) :10(4)A 250VAC T125 1E4
16A 125V/10A 250VAC 1/3HP 125-250VAC T105

EXPLANATION OF MODEL NUMBER


R L 3 - 3 -
1 1 / N
- G
- 2
- R E / B K
- P 4

|
|
|
|
|

Function
Current
Cap Printing
Cap/Housing Color
Terminal

Function
11/N
ON-OFF 3P
W/Lamp
00
Indicator Lamp
Current
G
10A125VAC
6A250VAC
H
16A125VAC
10A250VAC
Cap/Housing
Color
BK
Black
WT
White
GE
Grey
RE
Red
GR
Green
BL
Blue
OR
Orange
Terminal
Cap Printing
0
None
1
2
3
8
15
